12
TROUBLESHOOTING
12.3 Error Code List
12.3.6 Error code list (4000 to 4999)
12 - 43
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
4000
• The program contains an instruction
code that cannot be decoded.
• An unusable instruction is included in
the program.
Read the common information of the
error using a GX Developer, check error
step corresponding to its numerical
value (program error location), and
correct the problem.
QS
4002
• The name of dedicated instruction
specified in the program is incorrect.
• The dedicated instruction specified in
the program cannot be executed by
the specified module.
• An unsupported instruction exists.
QS
4003
The number of devices for the
dedicated instruction specified in the
program is incorrect.
4004
The device, which cannot be used by
the dedicated instruction specified in
the program, is specified.
4010
There is no END instruction in the
program.
QS
4100
The instruction cannot process the
contained data.
Read the common information of the
error using the GX Developer, check
error step corresponding to its
numerical value (program error
location), and correct the problem.
QS
4101
• The designated device number for
data processed by the instruction
exceeds the usable range.
• Alternatively, the stored data or
constants for the devices designated
by the instruction exceeds the usable
range.
Read the common information of the
error using the GX Developer, check
error step corresponding to its
numerical value (program error
location), and correct the problem.
QS

Mitsubishi MELSEC Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	MELSEC
Programming Languages	Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
Communication Protocols	Ethernet, CC-Link, RS-232, RS-485, USB, Profibus, Modbus
Model Series	FX, Q, L, iQ-R, iQ-F
Input Voltage	100-240V AC, 24V DC (varies by model)
Memory Capacity	Varies widely depending on the CPU module and series. Ranges from kilobytes to megabytes.
I/O Points	16 to 8192 points (varies by model)
Communication Ports	Ethernet, RS-232, RS-485, USB (varies by model)
Programming Software	GX Works2, GX Works3, GX Developer
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 75°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	10 to 57Hz, 0.075mm amplitude; 57 to 150Hz, 9.8m/s² acceleration
Shock Resistance	147m/s², 3 times in each direction (X, Y, Z)
Protection Class	IP20 (varies by model)
CPU Processing Speed	0.02μs to 0.1μs per instruction (varies by model)
