12
TROUBLESHOOTING
12.3 Error Code List
12.3.6 Error code list (4000 to 4999)
12 - 45
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
4102
• The network number and/or station
number specified by the dedicated
instruction are incorrect.
• The module number, network
number, and/or number of character
strings specified by the dedicated
instruction exceed the allowable
range.
Read the common information of the
error using the GX Developer, check
error step corresponding to its
numerical value (program error
location), and correct the problem.
QS
4700
The S.QSABORT instruction was
executed, and the program was
forcefully stopped.
Remove the cause before executing the
S.QSABORT instruction.
QS
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
