4.1 Performance Specifications
4 - 2
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT
7
BATTERY
8
CPU MODULE START- UP PROCEDURES
Remark
For the general specifications, refer to CHAPTER 3.
Table4.1 Performance Specifications (Continue)
Item QS001CPU Remarks
No. of device points
Internal relay [M] 6144 points by default (M0-6143) (changeable)
The number of points
can be changed within
the setting range.
( QSCPU User's
Manual
(Function
Explanation,
Program
Fundamentals)
Link relay [B] 2048 points by default (B0 to 7FF) (changeable)
Timer [T]
512 points by default (T0 to 511) (changeable)
(Sharing of low- and high-speed timers)
The low- and high-speed timers are specified by the instructions.
The measurement unit of the low- and high-speed timers is set up by
parameters.
(Low-speed timer: 1 to 1000ms, 1ms unit, 100ms by default)
(High-speed timer: 0.1 to 100ms, 0.1ms unit, 10ms by default)
Retentive timer [ST]
0 point by default
(sharing of the low- and high-speed retentive timers) (changeable)
The low- and high-speed retentive timers are specified
by the instructions.
The measurement unit of the low- and high-speed retentive timers
is set up by parameters.
(Low-speed retentive timer: 1 to 1000ms, 1ms unit, 100ms by default)
(High-speed retentive timer: 0.1 to 100ms, 0.1ms unit, 10ms by default)
Counter [C] Normal counter: 512 points by default (C0 to 511) (changeable)
Data register [D] 6144 points by default (D0 to 6143) (changeable)
Link register [W] 2048 points by default (W0 to 7FF) (changeable)
Annunciator [F] 1024 points by default (F0 to 1023) (changeable)
Edge relay [V] 1024 points by default (V0 to 1023) (changeable)
Link special relay [SB] 1536 points (SB0 to 5FF)
The number of device
points is fixed.
Link special register [SW] 1536 points (SW0 to 5FF)
Special relay [SM] 5120 points (SM0 to 5119)
Special register [SD] 5120 points (SD0 to 5119)
RUN/PAUSE contact
One contact can be set up in X0 to 17FF for each of RUN. No PAUSE
contact.
Setting by parameters.
Timer function
Year, month, date, hour, minute, second and day-of-week
(leap year automatically identified)
Accuracy: -3.18 to +5.25s (TYP.+2.14s)/d at 0
Accuracy: -3.18 to +2.59s (TYP.+2.07s)/d at 25
Accuracy: -12.97 to +3.63s (TYP.-3.16s)/d at 55
----
Allowable instantaneous power failure
period
Varies depending on the power supply module. ----
5VDC internal current consumption 0.43A ----
External dimensions
H 98mm (3.86inch) ----
W 55.2mm (2.17inch) ----
D 113.8mm (4.48inch) ----
Weight 0.29kg ----
Protection of degree IP2X ----

Mitsubishi MELSEC Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	MELSEC
Programming Languages	Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
Communication Protocols	Ethernet, CC-Link, RS-232, RS-485, USB, Profibus, Modbus
Model Series	FX, Q, L, iQ-R, iQ-F
Input Voltage	100-240V AC, 24V DC (varies by model)
Memory Capacity	Varies widely depending on the CPU module and series. Ranges from kilobytes to megabytes.
I/O Points	16 to 8192 points (varies by model)
Communication Ports	Ethernet, RS-232, RS-485, USB (varies by model)
Programming Software	GX Works2, GX Works3, GX Developer
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 75°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	10 to 57Hz, 0.075mm amplitude; 57 to 150Hz, 9.8m/s² acceleration
Shock Resistance	147m/s², 3 times in each direction (X, Y, Z)
Protection Class	IP20 (varies by model)
CPU Processing Speed	0.02μs to 0.1μs per instruction (varies by model)
