6 - 1
6.1 Specification
6
BASE UNIT
CHAPTER6 BASE UNIT
This section describes the specifications of the base units used in the PLC
system.
6.1 Specification
The base unit is a unit to which the CPU module, power supply module and/or intelligent
function module are installed.
Table6.1 Base unit specifications
Item
Type
QS034B
Number of I/O modules installed 4
Possibility of extension Disable
Applicable module QS series modules
5 VDC internal current consumption 0.10A
Mounting hole size
M4 screw hole or 4.5 hole (for M4 screw)
External dimensions
H 98mm (3.86inch)
W 245mm (9.65inch)
D 44.1mm (1.74inch)
Weight 0.28kg
Attachment
Mounting screw M4 14 4 pieces (DIN rail mounting adapter to be sold separately)
DIN rail mounting Adapter type Q6DIN2
