9.1 Requirements for Conformance to EMC Directive
9.1.1 Standards relevant to the EMC Directive
9
EMC AND LOW VOLTAGE DIRECTIVES
*1: QP : Quasi-peak value, Mean : Average value
*2: The PLC is an open type device (device installed to another device) and must be installed in a conductive control panel.
The tests for the corresponding items were performed while the PLC was installed inside a control panel.
Table9.1 Standards relevant to the EMC Directive (Continue)
Specification Test Item Test Details Standard Value
EN61131-2 :
2003
EN61000-4-2
Electrostatic discharge
immunity
*2
Immunity test in which
electrostatic is applied to the
cabinet of the equipment.
8kV Air discharge
4kV Contact discharge
EN61000-4-3
Radiated electromagnetic
field immunity
*2
Immunity test in which electric
fields are irradiated to the
product.
1.4GHz-2.0GHz, 80-1000MHz, 10V/m,
80%AM modulation 1kHz
EN61000-4-8
Power frequency
magnetic field immunity
*2
Immunity test in which the
product is installed in the
magnetic field of the induction
coil.
50Hz/60Hz, 30A/m
EN61000-4-4
Electrical fast transient/
burst immunity
*2
Immunity test in which burst
noise is applied to the power line
and signal line.
AC power line: 2kV
DC power line: 2kV
DC I/O, analog, communication line: 1kV
EN61000-4-5
Surge immunity
*2
Immunity test in which lightning
surge is applied to the power line
and signal line.
AC power line:
Common mode 2kV, differential
mode 1kV
DC power line:
Common mode 1kV, differential
mode 0.5kV
DC I/O, analog, communication (shielded):
Common mode 1kV
DC I/O, analog (unshielded):
Common mode 0.5kV, differential
mode 0.5kV
Communication (unshielded):
1kV
EN61000-4-6
Conducted disturbances
immunity
*2
Immunity test in which high
frequency noise is applied to the
power line and signal line.
0.15-80MHz, 80%AM modulation 1kHz,
3Vrms

Mitsubishi MELSEC Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	MELSEC
Programming Languages	Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
Communication Protocols	Ethernet, CC-Link, RS-232, RS-485, USB, Profibus, Modbus
Model Series	FX, Q, L, iQ-R, iQ-F
Input Voltage	100-240V AC, 24V DC (varies by model)
Memory Capacity	Varies widely depending on the CPU module and series. Ranges from kilobytes to megabytes.
I/O Points	16 to 8192 points (varies by model)
Communication Ports	Ethernet, RS-232, RS-485, USB (varies by model)
Programming Software	GX Works2, GX Works3, GX Developer
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 75°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	10 to 57Hz, 0.075mm amplitude; 57 to 150Hz, 9.8m/s² acceleration
Shock Resistance	147m/s², 3 times in each direction (X, Y, Z)
Protection Class	IP20 (varies by model)
CPU Processing Speed	0.02μs to 0.1μs per instruction (varies by model)
