Appendix A: Product Specifications
45
Appendix A: Product Specifications
CE Mark Compliance
Electromagnetic Compatibility
1
Low-Voltage Requirements
Installation Category
Pollution Degree
Product Safety and Liability
EMC Directive 89/336/EEC
Low-Voltage Directive 73/23/EEC
II, according to EN 61010-1
2, according to IEC 664
Product Safety Directive 92/59/EEC
External Set Point 0 to 5 VDC analog (40K load impedence)
Fuse Ratings
115 VAC
230 VAC
0.50 A (T) / 250 V / 5 x 20 mm
0.25 A (T) / 250 V / 5 x 20 mm
Input Commands CLOSE and MANUAL
Input Signal 0 to 10 VDC, 0 to 1 VDC, or 0 to 0.1 VDC
(switch selectable on front panel)
Operating Temperature 0
o
to 40
o
C (32
o
to 104
o
F)
Output Power + and - 15 ±0.6 VDC @ 250 mA maximum
Power Consumption 50 VA maximum (50/60 Hz)
Power Requirement
115 VAC Setting
230 VAC Setting
100 to 120 VAC nominal
220 to 240 VAC nominal
Regulation ±0.25% of full scale
Valve Outputs
Current
Voltage
0 to 120 mA
0 to 110 VDC
Voltage Outputs
Input signal
Controller output
0 to 10 Volts (5K min. resistance)
0 to 10 Volts (5K min. resistance)
Due to continuing research and development activities, these product specifications are subject to change without notice.
1
An overall metal braided shielded cable, properly grounded at both ends, is required during use.
