MKS SENTRY 1510A - Appendices; Appendix A: Specifications and Facility Requirements

Instruction Manual #122162 - Rev. C – March 2014 50
8. Appendices
8.1 Appendix A: Specifications and Facility Requirements
Specifications
English
Metric
Performance:
Negative Pressure Configuration
1 Inch Unit (-3 to -23 mm H
2
O)
2 Inch Unit (-3 to -47 mm H
2
O)
(Inches H
2
O)
-0.12 to -0.9
-0.12 to -1.85
(Pa)
-29 to -225
-29 to -461
Positive Pressure Configuration
1 Inch Unit (+3 to +23 mm H
2
O)
2 Inch Unit (+3 to +47 mm H
2
O)
(Inches H
2
O)
+0.12 to +0.9
+0.12 to +1.85
(Pa)
+29 to +225
+29 to +461
Flow (Process) Operating Range
0.01 to 1.05
SCFM
0.3 to 30 SLM
Accuracy to Set Point
Dry Process (  1 mm H
2
O)
Pyrogenic Process (  2 mm H
2
O)
 0.04” H
2
O
 0.08” H
2
O
 10 Pa
 20 Pa
Response Time
Response to pyrogenic ignition
and extinguish varies by
installation.
Physical:
SENTRY 1510 Controller Length
Width
Height
Weight
7.5”
3.0”
8.5”
7 lbs.
191 mm
76 mm
216 mm
3.2 Kg
SENTRY TIM-100/120 Length
Width
Height
Weight
7.5”
5.2”
1.9”
2 lbs.
191mm
132mm
48mm
0.9 Kg
SENTRY Supervisor Length
Width
Height
Weight
7.9”
6.0”
2.3”
3 lbs.
201mm
152mm
58mm
1.4 Kg
CD-20 with SENTRY 1510 Length
Width
Height
Weight
38.1”
11”
3.9”
22 lbs.
967 mm
280 mm
98 mm
10 Kg
AVP Condenser with 1510 Length
Width
Height
Weight
47.3”
13”
3.9”
22 lbs.
1201 mm
330 mm
98 mm
10 Kg
CD-20 and AVP Condenser Active
Condensation Surface Area
142 in
2
917 cm
2
Material (Exhaust Path)
Ryton, Teflon, Viton Elastomers
Electrical:
Set Point Control Types
Supervisor or TIM-100 Only
0 to 5 Volt Analog Interface
RS422/485 Serial Interface up to
9600 Baud
Stand Alone Operation Using
Key Pad (TIM-120 requires TIM-
200 Program Module)
Power Requirement DC
(User Supplied)
Supervisor
TIM-100/120
+15 to +24 VDC, 500mA and
–15 to –24 VDC, 50mA
+15 to +24 VDC, 650mA and
–15 to –24 VDC, 50mA
- OR -
AC
(BAI Universal Power Supply)
Nominal
Operating
Supervisor
TIM-100/120
Supervisor or TIM-100/120
100 to 250 VAC, 50 to 60 Hz
90 to 260 VAC, 47 to 63 Hz
9.5W Nominal
12W Nominal
30W Maximum Available)
Safety cut-off device Supervisor
The Supervisor on/off switch
functions as a circuit breaker in
the event of over-current.
Specifications
English
Metric
TIM-100/120
The SENTRY TIM-100/120
contains a cartridge fuse holder
for a 5 x 20mm fuse. The fuse is
a 0.8 amp fuse (BAI P/N 12270).
AC Disconnect Device
The Supervisor and TIM-100/120
both rely upon the process tool or
house facility for AC mains
disconnect and start/stop device.
Operating Environment:
Process Gas Temperature at Input
212F
100C
Ambient Temperature
40-105F
4-40C
Relative Humidity (environment)
30% - 90% non-condensing
Altitude (above sea level)
Up to 6500 ft.
Up to 2000 m
IP Rating
IP20
Equipment is for indoor, pollution degree 2 use only.
Connections:
Input (From Process)
1” Female NPT. Connect using
1” Male NPT fitting.
Output (to Facility Exhaust)
1” Female NPT. Connect using
1” Male NPT fitting.
Nitrogen/CDA Supply Line
¼” OD Tube
NA
1510 Drain Port (vertical install)
¼” Female
NPT
NA
Process and/or Exhaust Drain
¼” OD Min.
6 mm OD Min.
AVP Condenser Drain
½” OD Tube
N/A
Condenser Water Supply Line
Condenser Water Return Line
¼” OD Tube
¼” OD Tube
N/A
N/A
Facility Requirements:
Facility Exhaust
Negative Pressure Configuration
Min
Positive Pressure Configuration
Min.
All Configurations Max.
0.4” H
2
O more
negative than
set point
-0.5” H
2
O
-5” H
2
O
98 Pa (10 mm
H
2
O) more
negative than
set point
-123 Pa (-13
mm H
2
O)
-1226 Pa (-125
mm H
2
O)
Nitrogen
Nitrogen Supply Pressure at 1510
2.8 Kg/cm
2
Min.
7.0 Kg/cm
2
Max.
40 PSI
100 PSI
274.4 KPa
686 KPa
Minimum Grade
House Grade or Better
Condenser Water
Minimum Water Cleanliness
Input Temperature
Minimum Flow Rate
Maximum Pressure (1.4Kg/cm
2
)
N/A
40-100F
15 GPH
20 psig
100 m
4-38C
1 LPM
137.2 KPa
Drain (Process)
1
Dry Process
Wet Process
Not Required.
Auto-drain or p-trap required.
2
Drain (Exhaust)
1
Dry Process
Wet Process
Recommended/Required.
2
Recommended/Required.
2
Condenser (moisture removal)
Required for wet processing.
Installation Platform
Level within 3 of horizontal or
vertical depending on model.
1
If using a p-trap, the active height of the p-trap should be 6” (150 mm)
or twice the maximum house exhaust available (i.e. 3” H
2
O exhaust = 6”
p-trap height; 75 mm H
2
O exhaust = 150 mm p-trap height) whichever
is greater.
2
Drain requirements vary by installation, configuration and process use.
Refer to instructions for additional details or contact technical support to
discuss installation or tool specific requirements.
