MKS SENTRY 1510A - Appendix D: Tool;Host to Cable Matrix

Instruction Manual #122162 53
8.4 Appendix D: Tool/Host to Cable Matrix
Part
Number
CE (Y/N)
Length
(FT.)
Host End
Host End Pin
Number
TIM-100/120 End
(or legacy Supervisor)
Connector
Plug /
Receptacle
Label
0-5V Set Point
0-5V Read Out
Analog Common
-15VDC
DC Common
+15VDC
Connector
Plug /
Receptacle
Label
W201-15-S
Y
15.0
9-pin DB
Plug
P1
6
2
7
5
4
3
9-pin DB
Receptacle
P2
W201-20-S
Y
20.0
9-pin DB
Plug
P1
6
2
7
5
4
3
9-pin DB
Receptacle
P2
W204-12-S
Y
12.0
9-pin DB
Plug
P2A
1
2
3
4
5
6
9-pin DB
Receptacle
P2
W207-12-S
Y
12.0
9-pin DB
Plug
P1
8
7
1
3
5
4
9-pin DB
Receptacle
P1A
W212-15-S
Y
15.0
9-pin DB
Plug
P1
8
7
5
3
1
4
9-pin DB
Receptacle
P2
W203-150
N
12.5
9-pin DB
Plug
P1
8
7
9
3
5
4
37-pin
AMP
Receptacle
P1A
W204-102
N
8.5
37-pin AMP
Plug
P2A
1
2
3
4
5
6
10-pin
Conxall
Plug
P2
W201-15
N
15.0
9-pin DB
Plug
P1
6
2
7
5
4
3
10 pin
Conxall
Plug
P2
W201-20
N
20.0
9-pin DB
Plug
P1
6
2
7
5
4
3
10 pin
Conxall
Plug
P2
W202-15
N
15.0
10-pin JAE
Receptacle
P1
5
3
4
9
6
1
10 pin
Conxall
Plug
P2
W212-15
N
15.0
9-pin DB
Plug
P1
8
7
5
3
1
4
10-Pin
Conxall
Plug
P2
Host End
TIM End 
SEE TABLE BELOW
Host End, SEE TABLE FOR PIN OUT
CE
Non-CE
 Host End, SEE TABLE FOR PIN OUT
9-PIN DB
PLUG
9-PIN DB
RECEPTACLE
10-PIN CONEXALL
RECEPTACLE
10-PIN JAE
RECEPTACLE
