Notes:
1 Process Exhaust Set Point.
2 Pressure Full Scale=5.000” H
2
O
3 Analog Input Full Scale = 5.000 volts.
4 To save menu configuration in permanent memory (1) press *,
(2) press to code 0, (3) press to code 77, (4) press ENT
5 User settable. Cannot be stored.
6 Use “Single” for set point entered by keypad or for Serial interface.
Use “Analog” for analog set point control
7 Use “Enable” for “Fast Set Point” mode
Use “Disable” for “Universal Fast Set Point”
8 Use Cls_Lp for standard set point control.
Use BlsLKI for Fast Set Point and Universal Fast Set Point.
9 Fast Set Point reserves these locations to store set point value and
position information: Pres SP1~4, and Pos SP1~4.
Universal Fast Set Point reserves only locations Pos SP1~4, and set
point values are stored in non-viewable memory.
10 The FSP set points can be viewed here when using the Fast Set
Point mode.
