Q26 Camera Manual: Product Overview
Drilling Template On-Wall Set
Notes
You can download the drilling template from www.mobotix.com (applies to both 0°
and 10° On-Wall Set).
Make sure that the drilling template is not scaled or adjusted to the paper size when
printing the PDF le (enlarged or reduced).
The maximum torque for all screws is 1 to 1.2 Nm.
ø 166 mm/6.54 in
74
mm/2.91 in
ø 160 mm/6.3 in
85 mm/3.35 in
