Q26 Camera Manual: Installation
2.2 Mounting the Camera Without Accessories
2.2.1 Mounting Instructions
The Q26, being an overview camera, is primarily designed for installation on walls or
ceilings. Direct installation of the camera without any accessories is, in general, always
possible, however - due to elevation of the rear casing of the camera where connections
and their holders are - a ush-mounted wall outlet should be installed rst.
The drilling template also includes a blue circle marking the minimum size and position of
this wall outlet, in addition to the drilling holes. To guarantee maximum coverage of the
room by the camera, the Q26 should be positioned on the wall or ceiling as close to the
middle of the room as possible.
Installation over a standard
ush-mounted wall outlet
(minimum installation
depth 20 mm/8 in)
