65
Preparing the Installation
3. Mount the camera to the stand using the two stainless steel
Allen screws.
4. Use the Torx screw to fasten the mount onto the wall. Make
sure that the head of the screw is not tight against the wall,
but that it still has 5 mm/0.2 in to go.
5. Slide the entire assembly from above over the Torx screw in
the wall.
6. Properly tighten the Torx screw to secure the assembly in
the desired position. There is a special hole in the Stand/Wall
Mount to access the Torx screw.
Caution
The Stand/Wall Mount has been only designed used for testing purposes. Make sure that
you replace this mount by a proper wall mount before bringing the system into service.
5 mm/
0.20 in
