6. CONFIGURATION
31
b) Item REPORT
The following screen appears:
→ PRINTOUT MODE +
NR. COPIES ↑
PRINT LAST ↓
EXIT -
Select item PRINTOUT MODE to chose the mode the data are printed: The following
options appear:
→
AT CYCLE END +
STEP BY STEP ↑
EXIT ↓
-
Select AT CYCLE END to print the report al the end of the cycle.
Select STEP BY STEP to print the data at each phase of the cycle, as result in the
normal printout (see Examples of printed report in Appendix B).
NOTE
IN STEP BY STEP MODE IS NOT POSSIBLE MORE REPORT COPIES.
T
HE VACUUM AND HELIX TEST REPORT PRINT IS CARRIED OUT ONLY IN MODE “AT
CYCLE END”.
Activate NR. COPIES to set the number of copies of the cycle report to print at the end
of the program. The following text appears:
COPIES: XX
+/- to set
↵ to enter
Ç to exit
Set the number of copies desired (up to a maximum
of 5). Confirm with the ↵ key.
On the other hand, the selection PRINT LAST reprints the report for the last cycle
executed (whether it terminated correctly or was interrupted by an alarm). The
following screen appears:
→ NORMAL PRINT +
EXTENDED PRINT ↑
EXIT ↓
-
The NORMAL PRINT command activates normal printing (that with salient cycle data
produced at the end of a correctly executed cycle), while EXTENDED PRINT activates
complete printing (including all the data typical of a cycle interrupted by an alarm).
