SUMMARY TABLE
Device Steam Sterilizer
Classification (as per 93/42 CEE)
II
Model
Manufacturer
M.O.COM. S.r.l.
Via delle Azalee, 1
20090 BUCCINASCO (MI) - ITALY
Power supply voltage
220V – 240 V~
Frequency 50/60 Hz
Mains fuses
(6.3 x 32 mm)
F 16A 250V
On-board fuses (board type “G”)
(5 x 20 mm)
F1: T 5A 250V (trafo secondary winding– 24V)
F2: T 2A 250V (digital signal 5V/analog 12V)
F3: T 2A 250V (trafo primary winding – 230V)
F4: F 200mA 250V (door-locking protection)
F5: F 1.25A 250V (door-locking gear motor overload)
F1 PTR: T 5A 250V (printer protection)
On-board fuses (board type “T”)
(5 x 20 mm)
F1: T 6,3A 250V (trafo secondary winding)
F2: T 3.15A 250V (trafo primary winding)
F1 PTR: T 3,15A 250V (printer protection)
External dimensions (LxDxH) 480 x 660x 420 mm (excluding rear connections)
Nominal power 2300 W (10A)
Insulation class
Class I
Installation category
Cat. II
Environment of use
Internal use
Noise level <60 db(A)
Environmental operating conditions
Temperature: +15 °C ÷ +40 °C
Relative humidity: max 80%, non-condensing
Altitude: max 3000 m (a.s.l.)
Net weight
about 58 kg (empty)
about 63 kg (empty with trays and support)
about 67 kg (empty, with trays and supports and water at MAX level)
Sterilization chamber dimensions
(Ø x D)
250 x 450 mm
Sterilization chamber total volume about 21 l (0.021 m
3
)
Sterilization chamber useful volume
(with tray supports inserted)
about 13 l (0.013 m
3
)
Distilled water tank capacity
(supply)
about 4.6 l (water at MAX level)
about 0.8 l (water at MIN level)
Sterilization programs
Available: 11 (see Appendix B)
Pre-sets: 4 (direct selection by user)
Test programs
HELIX/BD Test
Vacuum Test
Preheating time (from cold) about 10 minutes
Serial connection DB-9 pin (female) connector
Bacteriological filter
(PTFE filtering element)
Porosity: 0.2 µm
Connection: male 1/8" NPT connector
