Mocom SUPREME 17 - Page 56

Sterilizers SUPREME - FUTURA - CLASSIC (17-22-28)
- TECHNICAL MANUAL
54
SERVICE MENU
EN
SQ10 – CHECK EV5 FOR PROPER CLOSING
- remove steel plate (1) to
separate the door cover from the
crossbar/porthole unit
- be careful with the
spring/cylinder units (2)
- close the door
- access the SERVICE menu
- select COMPONENT TEST
- from SOLENOID VALVES menu:
- open EV1 and EV4
- close the other solenoid
valves, if open
- go to the OTHER
COMPONENTS menu
- activate VP – vacuum pump
- go to the SOLENOID VALVES
menu
With EV5 closed (not activated),
there should be no air suction from
the middle of the bacteriological
filter.
With EV5 open (activated), there
should be air suction from the
middle of the bacteriological filter.
- de-activate the components after
completing the test
