10.2.2 Star Supply Wiring
WARNING
Ensure that the controller has been isolated from all power sources before
the wiring is changed.
IMPORTANT
Use only a 5 core supply cable for Star connection.
Note: ve core cable only. Neutral line wired.
L1
L2
L3
Neutral
Earth
Figure 10-3 Star supply wiring
