Controller User Manual
version 2
Original Instrucons

Table of Contents

Questions and Answers

  • R
    Robyn MurphyAug 17, 2025
    What to do if the fuse keeps blowing on my Mold-Masters E-Multi EM1?
    • T
      Troy HartAug 17, 2025
      If the fuse for a zone has failed in your Mold-Masters Controller, it indicates a fault external to the controller. You should identify and fix the fault before replacing the fuse. Replace it with a fuse of the same rating and type, such as a High Rupture Current load fuse. The blown fuse can be found either on the control card or on the off-board triac module, if one is installed.
  • S
    stoutmistyAug 20, 2025
    How to fix an open circuit thermocouple on my Mold-Masters E-Multi EM1?
    • E
      ewatsonAug 20, 2025
      If your Mold-Masters Controller detects an open circuit thermocouple, for immediate recovery, you can slave that control zone to an adjacent zone or switch to open loop control. Afterwards, check if the input fuse on the control card has ruptured. If the fuse is intact, then replace the thermocouple.
  • S
    stephen41Aug 22, 2025
    How to troubleshoot a thermocouple reading -100C on my Mold-Masters Controller?
    • L
      Lisa LyonsAug 23, 2025
      If a thermocouple on your Mold-Masters Controller displays -100°C, indicating it's defective, test the thermocouple at the support beam or hot runner connector. Thermocouples in the same area should show similar output. If the output differs significantly, replace the thermocouple. If the new thermocouple also reads -100°C, there's likely a wiring problem; inspect the wiring and connections.
  • M
    molly43Aug 26, 2025
    What causes an earth fault on my Mold-Masters E-Multi EM1 Controller?
    • M
      Matthew UnderwoodAug 26, 2025
      If your Mold-Masters Controller system detects an earth fault, check the heater wiring for a low impedance path to earth.
  • B
    butlersaraAug 28, 2025
    Why is there no temperature rise in a zone on my Mold-Masters E-Multi EM1 Controller?
    • V
      Victor WagnerAug 28, 2025
      If no temperature rise is detected in a zone on your Mold-Masters Controller, the heater wiring may be faulty, or the element may be an open circuit. Check the thermocouple wiring, as it may be reversed.
  • B
    Brian BensonAug 31, 2025
    What to do if the water-flow sensor detects high flow rate on my Mold-Masters E-Multi EM1?
    • A
      Amanda WilliamsAug 31, 2025
      If the water-flow sensor on your Mold-Masters Controller detects a high flow rate, ensure that the coolant water system is not blocked or leaking.
  • M
    Mark BartlettSep 2, 2025
    How to check heater resistance on Mold-Masters E-Multi EM1?
    • R
      russell71Sep 2, 2025
      Check the resistance across the pins of your Mold-Masters Controller. A 1000W heater should show around 48 ohms, while a 500W heater should show about 96 ohms.
  • R
    Ruben ShortSep 5, 2025
    What to do if the RTD zone detects a temperature over 99C on my Mold-Masters E-Multi EM1 Controller?
    • J
      johnharrisSep 5, 2025
      If the RTD zone on your Mold-Masters Controller detects a temperature exceeding 99°C, check the wiring for any faults. Also, verify that the correct RTD is installed.
  • H
    Hunter CarterSep 8, 2025
    What to do if no mains supply synchronisation pulses are being received by my Mold-Masters Controller?
    • L
      Lacey ThomasSep 8, 2025
      Check the supply wiring of your Mold-Masters Controller for the presence of all three phases.
  • D
    donna27Sep 12, 2025
    What to do if the controller card is not responding in my Mold-Masters Controller?
    • B
      Brian JohnsonSep 12, 2025
      Check the card for faults on your Mold-Masters Controller.

Summary

Section 3 - Safety

3.2 Safety Hazards

Details common safety hazards associated with injection molding equipment.

3.3 Operational Hazards

Lists potential hazards during the operation of the equipment.

3.6 Lockout Safety

Emphasizes procedures for safely locking out energy sources during maintenance.

3.9 E-Multi Controller Safety Hazards

Highlights specific safety hazards related to the E-Multi controller.

3.11 E-Multi Injection Unit Safety Hazards

Details potential hazards associated with the E-Multi injection unit.

Section 5 - Installation

5.2 Connect the Controller to the E-Multi

Details the cable connections between the controller and E-Multi.

5.4 Connect the Controller to the Molding Machine

Guides on connecting the controller to the molding machine.

Section 6 - Operation

6.2 Isolate the Controller

Describes how to safely isolate the controller from the power supply.

Section 7 - E-Multi Controller HMI Interface

7.3 E-Multi Touchscreen Interface

Describes the layout and main areas of the touchscreen interface.

7.6 Injection Settings Screen

Details how to adjust screw movement and transition points.

7.7 Hold Settings Screen

Explains how to adjust hold pressure settings.

7.21 Main Settings Screen

Central access point for configuration, service, and maintenance screens.

7.31 PID Settings

Adjusts PID parameters for various control loops.

7.37 Alarms Screen

Lists triggered alarms, their status, time, and description.

Section 8 - Maintenance

Section 9 - Troubleshooting

Fault and Warning Messages

Lists and explains fault and warning messages.

Mold-Masters E-Multi EM1 Specifications
