7.11 Integrated Hot Runner Temperature Control
(Option)
Lower Bar - E-Multi Screen
Navigation and System
Buttons
See “Bottom Bar - Screen Navigation
Buttons” on page 7-6.
Left Bar - Hot Runner
Temperature Control
Buttons
Scroll Buttons
For scrolling through the zone
rows and columns
Supervisor Level Settings
Hot Runner Control Setup Screen
Hot Runner Control Utilities Screen
Figure 7-9 Integrated hot runner controller overview screen
7-26
