Section 7 - E-Multi Controller
HMI Interface
WARNING
Ensure that you have fully read “Section 3 - Safety” before operating your
E-Multi controller.
7.1 Introduction
CAUTION
Values on the screen pictures in this manual may not reect the correct
values for your machine. Do not change settings based on the screen
pictures.
CAUTION
This part of the manual describes the touchscreen interface or Human
Machine Interface (HMI) and shows what functions and information are
available.
From the various screens you will be able to:
• Set individual nozzle temperatures. Set high and low temperature limits
for closed loop zone control.
• Congure and calibrate nozzle position and contact force.
• Create mold specic setups (recipes). These can be stored and called up
when molds are changed.
• Congure the injection sequence and monitor it.
• Congure the hold sequence and monitor it.
• Congure the plasticize sequence and monitor it.
• Use the software oscilloscope (SWO) functionality to monitor operation.
• Control the password protection on all settings.
• Print out any displays or data listings.
• Connect and monitor Euromap connection between the E-Multi, molding
machine and robot.
