Mold-Masters E-Multi EM1 - 8.5 Injection Axis Referencing

8.5 Injection Axis Referencing
CAUTION
The injection referencing routine veries the injection stroke by moving the
screw fully back and then fully forward.
Referencing will fail if the screw cannot achieve the full stroke.
CAUTION
1. Controller must be in setup mode with heats on and up to operating
temperature, carriage referenced and carriage retracted from the mold.
2. Navigate to the screw settings page.
3. In the lower left-hand area, tap the Reference button.
4. Conrm the dialog box that appears.
NOTE
Once the dialog is conrmed, the injection axis will move automatically.
5. Wait for the screw to move fully back and then fully forward. Referencing
is complete when the screw position is just below 0.
8-5
