7.21 Main Settings Screen
WARNING
Values on the screens in the manual may not reect the correct values for
your machine size. Do not change settings to the loaded parameters based
on the screen pictures.
This screen serves as a central access point for conguration screens as well
as service and maintenance screens. The functions available are determined
by the user access level.
Figure 7-23 Main setting screen
7-59
© 2020 Mold-Masters (2007) Limited. All Rights Reserved.
E-MULTI CONTROLLER HMI INTERFACE
E-Multi Controller User Manual
