Mold-Masters E-Multi EM1 - 7.38 Mold Data Screen

7.38 Mold Data Screen
Mold specic settings such as movement settings, prole, temperature
setpoints and others may be stored (saved) and recalled (loaded). The upper
section contains a table that shows the saved mold settings. A mold data
record contains the settings for proles, temperatures, mold height, etc.
Figure 7-42 Mold data screen
Table 7-57 Mold Data Screen Components
Screen Components
Element Description
Active
mold data
Currently loaded mold
settings.
Drive Selection of a drive
(local compact ash or
USB stick) for saving
and loading mold
settings.
Comment Comments about the
current mold settings.
