7.35 Delay Settings Screen
This screen is used to set delay times for the production operation. Delay
times adjusted in this screen only aect the manual and full automatic mode.
These settings have no eect on setup mode.
Figure 7-39 Delay settings screen
Table 7-54 Delay Setting Screen Components
Screen Components Description
Inject: Delay Delay time between carriage force being reached and the start of
injection.
If the nozzle is already forward this delay will still be added.
Recommended for use with sprue break only.
Decompression: Delay Delay time before nozzle is moved away from the mold.
Nozzle:
Forward Delay
Backward Delay
The duration between the plasticizing and the start of the nozzle's
forward movement is specied here.
The duration between the end of injecting and the start of the nozzle's
backward movement is specied here.
