7.11.3 Utilities Screen (Supervisor Level)
The Integrated Hot Runner Controller Utilities screen is used to change the
settings of the interlocks with the molding machine. These interlock signals
are not necessary for operation but are supplied for customer use if needed.
NOTE
The Utilities screen can only be accessed by supervisor credentials or
above level authorized personnel. See the electrical schematic for further
information.
Figure 7-12 Utilities screen (supervisor level)
7-35
© 2020 Mold-Masters (2007) Limited. All Rights Reserved.
E-MULTI CONTROLLER HMI INTERFACE
E-Multi Controller User Manual
