6. Assemble eyebolts and washers and install into the holes on the top of
the E-Multi controller. See Figure 3-10.
Figure 3-10 Install eyebolts and washers
7. Attach slings to all of the eyebolts. See Figure 3-5.
IMPORTANT
Slings must be attached securely to all four eyebolts.
Balance the load in the chain or lifting device before it is lifted more than a
few inches.
Minimize swinging by bringing the hook over the load appropriately.
Move powered hoists slowly into engagements with loads.
Figure 3-11 Attach slings to all four eyebolts
8. Lift the E-Multi controller from the crate.
Unpack the E-Multi Controller - continued
3-24
