Mold-Masters E-Multi EM1 - Figure 3-7 Remove Cross Brace Screws; Figure 3-8 Remove Screws from Side and Bottom

4. From the side of the crate marked with “FRAGILE OPEN THIS SIDE”,
remove the cross brace screws. See Figure 3-7.
Remove
cross brace
screws
Figure 3-7 Remove cross brace screws
5. From the side of the crate marked with “FRAGILE OPEN THIS SIDE”,
remove the screws down the sides and at the bottom of the crate. See
Figure 3-8.
Remove screws along sides
Remove screws along bottom
Figure 3-8 Remove screws from side and bottom
6. Remove the side of the crate marked with “FRAGILE OPEN THIS SIDE”.
7. Remove the remaining four screws holding the braces on the opposite
side of the crate and remove the braces.
Unpack the E-Multi Controller - continued
