SpectraMax iD3 Multi-Mode Microplate Reader User Guide
68 5054747 B
Load and Unload Microplates
The buttons on the left include to enable you to load or unload a microplate.
1.
Touch to move the microplate drawer outside of the instrument.
2. Place the microplate onto the drawer or remove the microplate from the drawer.
Note: Place the microplate on the microplate drawer in landscape orientation
with well A1 in the left corner closest to the instrument.
Item Description
1 Touchscreen
2 Well A1 on the microplate
3 Microplate drawer
Figure 3-22: Microplate drawer with microplate loaded
3.
Touch to move the microplate drawer inside the instrument.
CAUTION! To prevent damage to the instrument, the height of the microplate must
not exceed 22mm, including the lid if the microplate is lidded.
