molex Brad HarshIO 600 eIP - Electrical Power Data; Electrical Signal Data

HarshIO 600 eIP
•
16
•
IP67 IO-Link Modules for EtherNet/IP
Electrical Power Data
Module
4-pin power version
5-pin power version
Product Reference
TCIEI-888P-DYU
TCIEI-888P-D1U
Power
Power IN connector
Mini Change (7/8”), 4-pin, male, Maximum 8 A
Mini Change (7/8”), 5-pin, male, Maximum 8 A
Power OUT connector
Mini Change (7/8”), 4-pin, female, Maximum 8 A
Mini Change (7/8”), 5-pin, female, Maximum 8 A
Module & Input power (UB)
24 VDC, -20%/+25% (19.2 VDC / 30 VDC) protected against power crossing)
Warning, a voltage over 30 VDC may destroy the module
Operating current (UB)
87 mA
Output power (UL)
10 Amps
Over current detection:1.45 x 8 A (±15%) for at least 250ms
Operating current (UL)
24 VDC, -20%/+25% (19.2 VDC / 30 VDC) (protected against power crossing)
Warning, a voltage over 30 VDC may destroy the module
Functional Earth
10 Amps
Over current detection:1.45 x 8 A (±15%) for at least 250ms
Max draw current per I/O connector
4 A
Sensor power pin
Pin 1 (L+ / Sensor power supply)
Sensors draw current from
UB
Maximum current (per port)
1.6 A (L+)
Electrical Signal Data
Channels
Pin 2 (configured as)
Pin 4 (configured as)
I/O connector
M12 Ultra-Lock, 5-pole, female, A-Coded
Standard Digital Inputs
Number of Channel
8 channels max
8 channels max
Input type
PNP, compliant to IEC 61131-2 Type 3
PNP, compliant to IEC 61131-2 Type 1
On-state current
2.5 mA typ.
2.5 mA typ.
Off-state current
1 mA max.
1 mA max.
Input channel voltage (“1”)
10 V … 30 V
12 V … 30 V
Input channel voltage (“0”)
-5 V … 5 V
-5 V … 9 V
Input filter
0, 1, 3 and 5 ms (1ms by default)
500 ns
Standard Digital Outputs
Outputs draw current from
UL
UB
Channels
8 channels max
8 channels max
Output voltage (min)
UL – 1V
UB – 1V
Output type
PNP, current sourcing
PNP, current sourcing
Output current
2 A per channel
0.5 A per channel
Maximum output current
8.0 A at 25°C ; total for all outputs combined
8.0 A at 25°C ; total for all outputs combined with
all sensor supply current
Short circuit current (typical)
up to 6.5 A
up to 1.2 A
IO-Link C/Q
Number of IO-Link channels
N/A
8 channels max
IO-Link port type
N/A
Port class A
Physical interface
N/A
Support of COM1, COM2, COM3
Max Process Data length
N/A
32 bytes
Protocol
N/A
Compliant with IO-Link specifications
v1.1 and v1.0
