HarshIO 600 eIP
•
62
•
IP67 IO-Link Modules for EtherNet/IP
File (0x37)
Class Attributes
Id
Description
Get
Set
Limits
1
Revision


1
2
Max Instance


200
3
Number of Instance


9
32
Directory


 Supported  Not supported
Class Services
Id
Service
Param. Options
0Eh
Get_Attribute_Single
Instance Attributes
Id
Description
Get
Set
101…108
(DS File
#1…#8)
200 (EDS File)
01
State


1 = File Empty
2 = File loaded
2 = File loaded
3 =Transfer Upload Initiated
02
Instance Name


Void if File empty
“EDS and Icon Files”
03
Instance Format Version


0 if File empty
1
04
File Name


“DSFile#X.bin”
“EDS.gz”
05
File Revision


Shall be the EDS revision file
06
FileSize


Calculated
Calculated
07
File Checksum


Calculated
Calculated
08
Invocation Method


100 (user spec.)
255 (Not applicable)
09
File Save Parameters


0x10
0x00
10
File Type


0 (Read Write)
1 (Read Only)
11
File Encoding Format


0 (Binary)
1 (Compressed)
 Supported  Not supported
Instance Services
Id
Service
Param. Options
0Eh
Get_Attribute_Single
4Bh
Initiate_Upload
4Fh
Upload_Transfer
4Ch
Initiate_Download
50h
Download_Transfer
51h
Clear file
