IP67 IO-Link Modules for EtherNet/IP
EtherNet/IP
EtherNet/IP Fieldbus
Ethernet connectors
2 x M12, 4-pin, female, D-Coded, shielded
IP setting
DHCP (based on MAC & on Client_ID), Static IP, Stored IP
Protocol
EtherNet/IP Adapter according specification Vol 1-3.17 (CIP) and Vol 2 – 1.18 (EtherNet/IP)
Data access
Implicit messages for I/O data transfer
Implicit (I/O) connection
• 1x Exclusive Owner (EO) connection (with configuration data only)
• Up to 7 Listen Only (LO) connections (with or without configuration data)
• Up to 8 Input Only (IO) connections (with or without configuration data)
• 8 simultaneous connections (Ex: 1EO+ 4IO +3LO)
Explicit (EM) connection
• Up to 8 Class 3 connections (Connected and unconnected)
Supported CIP Objects
• 0x01 – Identity object
• 0x02 – Message Router object
• 0x04 – Assembly object
• 0x06 – Connection Manager object
• 0x37 – File object (EDS Upload & Upload/Download/Clear DS file)
• 0x47 – DLR object
• 0x48 – QoS object
• 0xF5 – TCP/IP Interface object
• 0xF6 – Ethernet Link object
• 0x310 – IO-Link object
Integrated Switch
• 2x ports integrated switch (with DLR capability)
• Speed: 100Mbps
• Auto negotiation
• Auto crossing
• Auto polarity
• 1x status Led / port
• Storm Protection against network loop (Broadcast, Multicast and Unicast packets)
Ethernet Packet
Manage up to 9000 packet/sec
Request Packet Interval (RPI)
from 1 ms up to 65535 ms (default 30 ms)
IP Address Conflict Detection
Yes
Quick Connect
Yes
DLR (Device Level Ring)
Yes (Ring Node, Beacon-Based)
QoS (Quality of Service)
Yes (Layer 3 supported only)
ODVA conformance
Yes (CT13)
