molex Brad HarshIO 600 eIP - IO-Link (0 X310)

HarshIO 600 eIP
•
65
•
IP67 IO-Link Modules for EtherNet/IP
IO-Link (0x310)
Class Attributes
Attr ID
Access Rule
NV-RAM
Name
Data Type
Description of
Attribute
Semantics of Value
1
Get
Revision
UINT
Revision of the Object
1
2
Get
Max Instance
UINT
Maximum number of
instance of this object
8
3
Get
Number of instances
UINT
Number of object
instances currently
created at this class
level of the device.
8
32
Get
Active Instances
BYTE
One bit represent one
instance, port
configured in IO-Link
mode
1 => IO-Link Port
0 => No IO-Link Port
Class Services
Service Code
Service Name
Description of Service
0x01
Get_Attribut_All
0x0E
Get Attribut Single
