HarshIO 600 eIP
•
20
•
IP67 IO-Link Modules for EtherNet/IP
4. System Description
Physical description
Power IN (Ui)
Power OUT (Uo)
Mounting screw (Functional Earth #0 – FE0)
I/O Connectors
Plastic label
3x Rotary switches
Ethernet Port (ETH1)
Ethernet Port (ETH2)
Mounting screw
(Functional Earth #2 - FE2)
Port 0
Port 1
Port 2
Port 3
Port 4
Port 5
Port 6
Port 7
Shield Plate
Shield Plate
Mounting screw
(Functional Earth #1 – FE1)
