IP67 IO-Link Modules for EtherNet/IP
For Output and IO-Link Process Data information, refer to output assembly #121 and assembly #122
Warning!
If the IO-Link Output Process Data size configured (ex: 4 bytes) is lower than the IO-
Link Output Process Data size of the connected IO-Link device (ex: 32 bytes), the
EtherNet/IP connection will be established and the first 4 output bytes of data will be
produced.
Configuration data mapping
Assembly #100 - Configuration data
Process Input Data (4 bytes)
DO Fail Safe Mode (1 bytes)
SO Fail Safe Mode (1 bytes)
ID Validation and Data Storage Modes (2 bytes)
Direct Param Page2 Enable (1 bytes)
Direct Param Page2 (16 bytes)
EFAM: Electrical Fault Acknowledgement Mode.
When an electrical fault occurs, the module provides a diagnosis about the event into the input assembly (byte
offset 02/03/04/05) and applies a protection strategy on pin2, pin4 and pin1. (Refer to the chapter Protection
Strategies on electrical fault).
0 = Automatic Acknowledgement and Notification only (NO)
If the electrical fault disappears, the module will automatically acknowledge the error and will remove
the protection strategy and output values are restored.
1 = Manual Acknowledgement and Notification & Protection (NP)
If electrical fault disappears, the module will not automatically acknowledge the error. As soon as the
user manually acknowledges the error (toggle bit “EFA”), the protection strategy is removed. Once
done, it goes in normal mode and output values are restored.
Warning!
Some electrical faults cannot be manually acknowledged even if EFAM is set to 1.
Please refer to chapter Protection Strategies on electrical fault.
