IP67 IO-Link Modules for EtherNet/IP
Input process data mapping
Assembly #110 - Digital data + with no IO-Link data
Process Input Data (8 bytes)
Bit
Offset (in byte)
7
6
5
4
3
2
1
0
00
DI7
SI6
DI5
SI4
DI3
SI2
DI1
SI0
01
DI15
SI14
DI13
SI12
DI11
SI10
DI9
SI8
02
PS7
PS6
PS5
PS4
PS3
PS2
PS1
PS0
03
n/u
OLUL
OVUL
UVUL
n/u
OLUB
OVUB
UVUB
04
CS7
CS6
CS5
CS4
CS3
CS2
CS1
CS0
05
CS15
CS14
CS13
CS12
CS11
CS10
CS9
CS8
06
IOML6
IOLM4
IOLM2
IOLM0
07
IOLM14
IOLM12
IOLM10
IOLM8
SIx: SI - Standard Input data (x = Channel number) – Pin4
DIx: DI - Digital Input data (x = Channel number) – Pin2
PSx: Port Status (x = Port number) - state of the pin1 (L+)
1: short circuit detected
0: No default
UVx: Under Voltage (x = UL or UB)
1: Under voltage detected
0: No default
OVx: Over Voltage (x = UL or UB)
1: Over voltage detected
0: No default
OLx: Over Load (x = UL or UB)
1: Over load detected
0: No default
CSx: Channel Status (x = Channel number) – State of the Digital Output (DO – pin 2) or Standard Output (SO
– pin 4)
1: short circuit detected
0: No default
IOLMx: IO-Link Communication Mode (x = Channel number)
0: IO-Link communication not activated
1: IO-Link communication activated
