HarshIO 600 eIP
•
60
•
IP67 IO-Link Modules for EtherNet/IP
TCP/IP Interface (0xF5)
Class Attributes
Id
Description
Get
Set
Limits
1
Revision


4
2
Max Instance


1
3
Number of instances


1
 Supported  Not supported
Class Services
Id
Service
Param. Options
01h
Get_Attributes_All
0Eh
Get_Attribute_Single
Instance Attributes
Id
Description
Get
Set
Values
NRAM
Rotary
DHCP
Static
DHCP
Static
1
Status


Obtained by BOOTP, DHCP or
stored Value
Obtained by BOOTP, DHCP or
stored Value
Obtained by BOOTP, DHCP
or stored Value
Valid con obtained by
hardware setting
I/F Configuration Pending: The bit 5 shall be set to 1 when the Interface configuration has changed (Set new IP parameters in the
attribute #5 or rotaries change).
ACD Fault: The bit 6 shall be set to 1 if the attribute #11 is not empty.
2
Configuration Capability


- DHCP Client
- Config. Settable
- Hardware Configurable
- Interface Configuration change requires reset
- ACD capable
 Expected values = 0xF4
3
Configuration Control


DHCP
Stored Value
DHCP
Stored Value
4
Physical Link


0x20 0xF6 0x24 0x03
5
Interface Configuration


Current values (see Rotaries chapter for details on how IP is calculated when set by rotaries)
6
Host Name


Values from DHCP server
Last saved values
Value is cleared at each reboot when IP is configured using
rotaries thus:
- Empty if no “set attribute” has been done since last
reboot.
- Current values in other cases
7
Safety Network Number


N/A
8
TTL Value


N/A
9
Mcast Config


N/A
10
Select ACD


Current ACD configuration
11
LastConflictDetected


If a conflict was detected return the last values else all values to 0
12
EtherNet/IP Quick_Connect


Current Quick Connect
13
Encapsulation Inactivity Timeout


Current Values (default 120)
 Supported  Not supported
Instance Services
Id
Service
Param. Options
01h
Get_Attributes_All
0Eh
Get_Attribute_Single
10h
Set_Attribute_Single
