molex Brad HarshIO 600 eIP - Mechanical and Environmental Data

HarshIO 600 eIP
•
19
•
IP67 IO-Link Modules for EtherNet/IP
Mechanical and Environmental Data
Mechanical
Housing dimensions
235 x 60 x 39 mm (9.25" x 2.36” x 1.53")
Housing material
PBT VALOX 420 SEO Black 7701
Flammability Standard
UL 94 V-0
Corner mounting holes
4 mounting holes, 5 x10 mm
Ground stud
Yes (allows the continuity of the ground when the module is mounted on the chassis machine)
Operating temperature
-25°c to +70°c
Storage temperature
-40°c to +90°c
Vibration resistance
Operating: 7mm p-p (5-15.7Hz), 7g (15,7Hz to 500Hz), 3 axis
Shock resistance
Operating: 15g, 11ms, 3 axis / Non-operating: 50g, 6ms, 3 axis
Electro-magnetic compatibility
EN 61000-6-2 / EN 61000-6-4
Relative humidity
10 % to 95 %, non-condensing
Protection Class
IP67
Approval
CE (according IEC 61131-2), UL / cUL
Environmental
RoHS and REACH
MTBF
100.000 Hours @ 70°C
Note!
This product was EMC tested for use in industrial areas. If it is to be used in personal or
business and trade environments, the resulting system must go through EMC
qualification.
