HarshIO 600 eIP
•
64
•
IP67 IO-Link Modules for EtherNet/IP
QoS (0x48)
Class Attributes
Id
Description
Get
Set
Limits
1
Revision


1
2
Max Instance


1
3
Number of Instance


1
 Supported  Not supported
Class Services
Id
Service
Param. Options
0Eh
Get_Attribute_Single
Instance Attributes
Id
Description
Get
Set
Limits
04
DSCP Urgent


DSCP value for CIP transport class 0/1 Urgent
priority messages. The default value shall be 55
05
DSCP Scheduled


DSCP value for CIP transport class 0/1
Scheduled priority messages. The default value
shall be 47
06
DSCP High


DSCP value for CIP transport class 0/1 High
priority messages. The default value shall be 43
07
DSCP Low


DSCP value for CIP transport class 0/1 Low
priority messages. The default value shall be 31
08
DSCP Explicit


DSCP value for CIP explicit messages (transport
class 2/3 and UCMM). The default value shall be
27
 Supported  Not supported
Instance Services
Id
Service
Param. Options
01h
Get_Attribute_All
0Eh
Get_Attribute_Single
10h
Set_Attribute_Single
