molex Brad HarshIO 600 eIP - Page 66

HarshIO 600 eIP
•
66
•
IP67 IO-Link Modules for EtherNet/IP
Instance Attributes
Attr
ID
Access
Rule
Name
Data Type
Description of
Attribute
Semantics of Value
1
Get
IO-Link Status
UINT
See input assembly
as well Validation status / Port Existing or not
Data Storage Status
2
Get
IO-Link
Configuration
STRUCT OF
UINT
Mode
0: None
1: Compatible
2: Compatible with Backup and Restore
3: Compatible with Restore
4: Identical
5: Identical with Backup and Restore
6: Identical with Restore
ARRAY OF 2 BYTE
Vendor Id
Only used is Mode is not set to “None”
ARRAY OF 3 BYTE
Device Id
Only used is Mode is not set to “None”
ARRAY OF 2 BYTE
Reserved
0
USINT
DPP2 enable
0 = FALSE
1 = TRUE
ARRAY OF 16 BYTE
DPP2
Only used is “DPP2 enable” is set to TRUE
3
Get
DPP1
STRUCT OF
Values comes from Device
ARRAY OF 2 BYTE
Vendor Id
ARRAY OF 3 BYTE
Device Id
USINT
Reserved
USINT
Protocol Id
USINT
ISDU support
USINT
SIO Mode Support
USINT
PD In Data Length
USINT
PD Out Data Length
USINT
Master Cycle Time
USINT
Min Cycle Time
4
Get
Serial
Number
Associated
SHORT_STRING
SN associated with
the IO-Port
Values comes from Device
5
Get
Serial
Number
SHORT_STRING
SN from IO-Link
Device Connected
Values comes from Device
6
Get
DS File
UINT
DS File Instance
7
Get
PDIn Len
USINT
Length in Byte
IO-Link slave input data len
8
Get
PDOut Len
USINT
Length in Byte
IO-Link slave output data len
9
Get
PDIn Data
ARRAY OF 32 BYTE
Current IO-Link slave input data
10
Get
PDOut Data
ARRAY OF 32 BYTE
Current IO-Link slave Output data
11
Get
Events
STRUCT OF
Events from IO-Link Device (Remote) or
Master (Local)
USINT
Number of Events
Size of Event details array (Max 64)
ARRAY OF STRUCT
Event Details
USINT
Seq Count
BYTE
EventQualifier
Type, mode and source of the Event
UINT
EventCode
The identifier of an actual Event
