Positive Response:
No data are set into the response.
Negative Response: Refer to the above chapter Service Read ISDU details
Example:
Changing the current input filter delay 1ms to 3ms of the Molex HarshIO IO-Link digital hubs (Refer to the
TEDIO-8D0P-808 user’s manual) connected to Port 0.
Parameters
Description
Class
0x310
IO-Link parameter object
Instance attributes
1
IO-Link port number where the IO-Link device is connected
Instance service
0x51
Write ISDU
Data
Name
Data type
Description
Index
UINT16
0x42 0x00
Sub-Index
UINT8
0x00
Reserved
UINT8
0x00
Len
UINT16
0x01 0x00
Data[]
SINT[1]
0x03 (5ms)
