5 • 206
2004 • LaPalma
Equipment
The slide-out system can be retracted in the event of a power loss.
If the Room Does NOT Move When the Switch is Pressed:
• The house battery cut-off switch must be on.
• Check if the battery is fully charged and connected.
• If applicable, make sure the locking bar mechanisms are removed.
After the previous items have been checked and the room still does not
move when the slide-out switch is pressed, use the following steps to
manually override the slide-out room:
• To move the slide-out room manually, retract the motorhome
leveling jacks (see “Leveling Jacks”).
• To move the slide-out room, move the lever on the drive motor
counterclockwise to release motor brake. The drive motor and
mechanism is located behind the slide-out storage
compartments. Turn the square shaft next to the drive motor
using a 1” wrench.
• Once the room is in position, apply pressure to the wrench so
that the room is sealed. Return the brake lever to its normal
position to lock the room in place.
• Take the motorhome to an authorized dealer for service.
NOTE: The slide-out room is heavy and may require
several persons to push it into the retracted position. Once the
slide-out room is in the fully retracted position, return the brake
level to the lock position to hold the room in place.
Manual Override
Main Slide-out
OM030749C
