NOTE: This chart reflects product specification available at the time of printing.
Therefore any floor plans thereafter may not be reflected in the chart. All other
information contained throughout the manual will still apply.
NOTE: All tank capacities are estimated based upon calculations provided by
the tank manufacturers and represent approximate capacities. The
actual “useable capacity” may be greater or less then the estimated
capacities based upon fabrication and installation of the tanks.
Air Filter FA-1634 Air Filter A1236C
Battery BXT-65-750 Fuel Filter GF481
Fuel Filter FG986B Oil Filter PF454
Oil Filter FL-820-S Spark Plugs 42-99321
PCV Valve EV-233 Radiator Cap RC33
Spark Plugs AWSF22E
8.1L V8 AS FUEL INJECTION
33PBD 34SBD 34PBD 34PDT 36PED 36WDD 36DBD 37PCD 37PCT
Gross Vehicle Weight Rating 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs.
Gross Combined Weight Rating 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs.
Front Gross Axle Weight Rating 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs.
Rear Gross Axle Weight Rating 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs.
WORKHORSE W-22 W-22 W-22 W-22 W-22 W-22 W-22 W-22
Gross Vehicle Weight Rating 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. N/A
Gross Combined Weight Rating 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. N/A
Front Gross Axle Weight Rating 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. N/A
Rear Gross Axle Weight Rating 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. N/A
MODELS 33PBD 34SBD 34PBD 34PDT 36PED 36WDD 36DBD 37PCD 37PCT
Water Heater 10 gal. 10 gal. 10 gal. 10 gal. 10 gal. 10 gal. 10 gal. 10 gal. 10 gal.
Grey Tank 42 gal. 40 gal. 42 gal. 42 gal. 54 gal. 54 gal. 42 / 39gal. 45 gal 45 gal
Black Tank 42 gal. 42 gal. 42 gal. 42 gal. 45 gal. 45 gal. 42 / 39gal. 54 gal 54 gal
Fresh Tank 60 gal. 60 gal. 60 gal. 60 gal. 60 gal. 60 gal. 60 gal. 60 gal 60 gal
LP Tank * 24 gal. 24 gal. 24 gal. 24 gal. 24 gal. 24 gal. 24 gal. 24 gal. 24 gal.
COMMON PARTS
SPECIFICATION
CHARTS
MODELS 33PBD 34SBD 34PBD 34PDT 36PED 36WDD 36DBD 37PCD 37PCT
Wheelbase 228" 228" 228" 228" 238" 238" 238" 242" 242"
Overall Length 33' 11" 34' 10" 34' 10" 34' 10" 36' 5" 36' 5" 36' 5" 36' 11" 36' 11"
Overall Height,
Including A/C, Ford
11'-9" 11'-9" 11'-9" 11'-9" 11'-9" 11'-9" 11'-9" 11'-9" 11'-9"
Overall Height,
Including A/C,
Workhorse
11'-8" 11'-8" 11'-8" 11'-8" 11'-8" 11'-8" 11'-8" 11'-8" 11'-8"
Interior Height 6' 6" 6' 6" 6' 6" 6' 6" 6' 6" 6' 6" 6' 6" 6' 6" 6' 6"
Interior Width 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5"
Exterior Width 100.5'' 100.5'' 100.5'' 100.5'' 100.5'' 100.5'' 100.5'' 100.5'' 100.5''
*Actual filled LP capacity is 80% of listing due to safety shut off required on tank.
Under Hood
9 • 350
2004 • LaPalma
