Monaco LaPalma - Four-Corner Weighing (Example)

2 • 83
Driving & Safety
2004 • LaPalma
NOTE: Following scale readings and Gross Axle Weight
Ratings are fictitious. Actual scale readings and Gross Axle
Weight Ratings will vary with model and options.
The motorhome must be weighed fully loaded to obtain accurate scale
readings and to determine the proper tire pressure. All slide rooms must be in
the retracted position.
• Take the rear axle Gross Axle Weight Rating (GAWR) and divide it by
two. Example: Rear axle GAWR taken from the motorhome Vehicle
Certification Label is 14,500 lbs. Divide the figure by 2, using chart
below, record 7,250 lbs. on Scale B and D, line 1.
• Weigh the driver side rear corner (Scale B) and record weight on chart
Scale B, line 2. Example: 4,400 lbs.
• Weigh the passenger side rear corner (Scale D) and record weight on
chart Scale D, line 2. Example: 4,100 lbs.
• Add chart Scale B and D, lines 1, for Gross Axle Weight Rating
(GAWR) and record on chart under Totals. Example: 14,500 lbs.
• Add chart Scale B and D, lines 2, for actual Gross Axle Weight (GAW)
and record on chart under Totals. Example: 8,500 lbs.
• Actual Gross Axle Weight (GAW). Example: 8,500 lbs., is not to
exceed Gross Axle Weight Rating (GAWR). Example: 14,500 lbs.
020152b
Four Corner
Weighing (Example)
