2 • 95
Driving & Safety
2004 • LaPalma
NOTE: This chart reflects product specifications available at the time of
printing. Therefore any floor plans introduced thereafter may not be reflected in
the chart. All other information contained throughout the manual will still apply.
NOTE: All tank capacities are estimated based upon calculations provided by
the tank manufacturers and represent approximate capacities. The actual
“usable capacity” may be greater or less then the estimated capacities based
upon fabrication and installation of the tanks.
SPECIFICATIONS - DIMENSIONS CHART
MODELS 33PBD 34SBD 34PBD 34PDT 36PED 36WDD 36DBD 37PCD 37PCT
Wheelbase 228" 228" 228" 228" 238" 238" 238" 242" 242"
Overall Length 33' 11" 34' 10" 34' 10" 34' 10" 36' 5" 36' 5" 36' 5" 36' 11" 36' 11"
Overall Height,
Including A/C, Ford
11'-9" 11'-9" 11'-9" 11'-9" 11'-9" 11'-9" 11'-9" 11'-9" 11'-9"
Overall Height,
Including A/C,
Workhorse
11'-8" 11'-8" 11'-8" 11'-8" 11'-8" 11'-8" 11'-8" 11'-8" 11'-8"
Interior Height 6' 6" 6' 6" 6' 6" 6' 6" 6' 6" 6' 6" 6' 6" 6' 6" 6' 6"
Interior Width 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5" 94.5"
Exterior Width 100.5'' 100.5'' 100.5'' 100.5'' 100.5'' 100.5'' 100.5'' 100.5'' 100.5''
33PBD 34SBD 34PBD 34PDT 36PED 36WDD 36DBD 37PCD 37PCT
Gross Vehicle Weight Rating 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs.
Gross Combined Weight Rating 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs.
Front Gross Axle Weight Rating 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs. 7,500 lbs.
Rear Gross Axle Weight Rating 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs.
WORKHORSE W-22 W-22 W-22 W-22 W-22 W-22 W-22 W-22
Gross Vehicle Weight Rating 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. 22,000 lbs. N/A
Gross Combined Weight Rating 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. 26,000 lbs. N/A
Front Gross Axle Weight Rating 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. 8,000 lbs. N/A
Rear Gross Axle Weight Rating 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. 14,500 lbs. N/A
MODELS 33PBD 34SBD 34PBD 34PDT 36PED 36WDD 36DBD 37PCD 37PCT
Water Heater 10 gal. 10 gal. 10 gal. 10 gal. 10 gal. 10 gal. 10 gal. 10 gal. 10 gal.
Grey Tank 42 gal. 40 gal. 42 gal. 42 gal. 54 gal. 54 gal. 42 / 39gal. 45 gal 45 gal
Black Tank 42 gal. 42 gal. 42 gal. 42 gal. 45 gal. 45 gal. 42 / 39gal. 54 gal 54 gal
Fresh Tank 60 gal. 60 gal. 60 gal. 60 gal. 60 gal. 60 gal. 60 gal. 60 gal 60 gal
LP Tank * 24 gal. 24 gal. 24 gal. 24 gal. 24 gal. 24 gal. 24 gal. 24 gal. 24 gal.
*Actual filled LP capacity is 80% of listing due to safety shut off required on tank.
