NOTE: Fuel mileage varies with driving style and road conditions.
Always average more than one tankful to obtain a more accurate
figure. The generator will use fuel from main tank and will affect
fuel mileage figures. The generator will not operate below 1/4 tank
to insure there is enough fuel to run main engine.
4. Engine Temperature Gauge: Normal operating temperatures
should be a midrange indication.
5. LCD Screen:
• Indicates transmission gear selection on vehicles equipped with
an automatic transmission (if the steering column is not
equipped with a gear selection indicator).
• Odometer with a maximum mileage accumulated to 999999.9
miles / km.
• Trip odometer 1 and 2 (independent functions).
• Battery voltage.
• Oil pressure or PRND321 (depends on the user selection).
• Warning messages to provide more detail if the vehicle condition
monitoring system detects a fault (this will interrupt monitoring
data displayed).
6. Trip Button:
• Selects and resets the trip 1 and 2 odometers.
• Scrolls upwards in the menu display.
• Is used with the Mode button to select menu choices and toggle
between Metric and US units.
• Displays the odometer reading when the ignition is OFF.
• Acknowledges the sounding of the buzzer and chimes.
7. Mode Button:
• Selects inquiry mode (only available if equipped with PRND321
display).
• Scrolls downward in the menu display.
• Is used with the Trip button to select menu choices and toggle
between Metric and US units.
• Displays the odometer reading when ignition is OFF.
8. Turn Signal LH Turn Active: An arrow is displayed on the
instrument panel to indicate a left hand turn
9. Turn Signal RH Turn Active: An arrow is displayed on the
instrument panel to indicate a right hand turn.
Electrical Systems
