8 • 329
4. Fuel: Fuel gauge will register approximate fuel level in tank
when ignition switch is in run position.
NOTE: Fuel mileage varies with driving style and road
conditions. Always average more than one tank full to
obtain a more accurate figure. The Generator will use fuel
from main tank and will affect fuel mileage figures. The
Generator will not operate below 1/4 tank to insure there is
enough fuel to run main engine.
5. Antenna Up Warning Light: This light illuminates when TV
antenna is in raised position with ignition switch ON. Do not
move motorhome until the antenna is lowered.
6. Speedometer: Indicates the speed of the motorhome. The gauge
indicates MPH and KPH. Located on center of the instrument
cluster.
7. Odometer: The odometer indicates the actual mileage of the
motorhome.
8. Trip meter: The trip meter will display the current mileage of
the trip since the last reset.
9. Reset Button: Used to reset the trip meter counter to zero.
10. Shift Selector: The indicator shows the position on the
transmission.
11. Tachometer: Displays engine speed in revolutions per minute
(RPM). Tachometer reads output pulse of alternator. If
tachometer quits, or indicates improperly, have alternator
checked immediately.
2004 • LaPalma
