User Manual
11
Chapter 4: DVR Start up
4.1、System Initialization
After connecting the Power cable of DVR to wall outlet and pressing the Power button on the front panel,
you will enter into the system initializing screen shown as Picture 4-1.
Note: The pictures illustrated by this manual will differ depending on your different monitor.
4.2、Live screen
After finishing initialization the system will enter into Live screen. Picture 4-2 is the 9-split display defaulted
by system, which is showing no video input status. Once there are video inputs, the screen will display live
images from the cameras. In Live mode, if you use the mouse to double-click the live image of any channel,
the image will be maximized to full screen, by double-clicking again, image will be come back to 4-split or
9-split display mode; clicking the right button of the mouse will enter into Pop-up Menu; clicking the left button
of the mouse allows you select menu items; and clicking any area outside the menu allows you exit the Pop-up
menu.
Note: When internal HDD is not connected or an error occurs, the character “H” will appear on the first
channel of the live screen and accompany buzzer alarm. If you want to close the buzzer alarm, please enter
into [Device manageAlarm setting] to set HDD loss and HDD space to “off”.
Chapter 5: DVR Menu
5.1、Pop-up Menu
After finishing system initialization, click right key of mouse on Live mode to enter into Pop-up Menu. Now
Picture 4-1 Picture 4-2
Picture 5-1c Picture 5-1b
Picture 5-1
