Monacor DMR152 - Rear Panel; 4-CH Rear Panel Layout

User Manual
7
2.2、Rear Panel
2.2.1、4-CH Rear Panel layout
2.2.2、8-CH Rear Panel layout
Item Physical port Connection method
1 Video in
p
ut
Connect CH1-4
(
Virtual
)
video in
p
ut device （ BNC
2 Video out
p
ut Connect monitor out
p
ut
(
BNC interface
)
3 Audio in
p
ut Connect CH1-4 audio si
g
nal in
p
ut
(
RCA interface
)
4 Audio out
p
ut Connect audio si
g
nal out
p
ut
(
RCA interface
)
5 Ethernet: Port Connect LAN, Ethernet
(
RJ45 interface
)
6 VG
A
Port Connect to VGA monito
r
, such as PC monitor
(
O
p
tional
)
7 USB Port Connect USB mouse
8 USB Port Connect USB device
(
Flash Drive, Hard Drive and Recorder etc
)
9
RS-485/Sensor/Alarm
RS485/Sensor/Alarm interface
(
see
p
in outs below
)
10 Power Port Connect
p
ower su
pp
l
y
- DC12V 3A/5A
A
B
A
B
List 2-3
