Chapter 7: Specifications
Device Parameter D9104 D9108
Video System NFSC/PAL(Optional)
Video/Audio
Compression Format
Video：H.264 Audio：8kHz*16bit ADPCM
Video I/O
4-CH BNC input/2-CH BNC
output； VGA (Optional)
8-CH BNC input/2-CH BNC output ；
VGA(Optional)
Audio I/O 4-CH input / 2-CH output 8-CH input / 1-CH output
Display Resolution D1：704×576(PAL) 704×480 (NTSC)
Display frame rate Single Channel PAL：25 fps ，NTSC：30 fps
Record Resolution
PAL: CIF(352*288) HD1(704*288) D1 (704*576）
NTSC:CIF(352*240) HD1(704*240) D1 (704*480)
Record Total frame rate
PAL：50 fps@D1、100 fps@HD1、200 fps @CIF
NTSC：60 fps@D1、120 fps @HD1、240 fps @CIF
PAL：400 fps @CIF
NTSC：480 fps @CIF
Image Quality Best / Good / Middle
HDD
Support USB removable HDD and SATA HDD
Record Mode
Always, Scheduled, Manual, Web Client record.
Pack Time
15/30/45/60 min (adjustable)
Backup Function
Support U flash disk, removable HDD, recorder and network backup；
Backup file format is *.264 format and network file will automatically be
backed-up to AVI format).
Playback Mode
Normal play, Fast Forward, Rewind and slow play frame by frame.
Alarm Mode
Video Loss, HDD Full, HDD Error
PTZ control Embedded RS-485 port / supports PELCO-P & PELCO-D protocol.
USB Port
Support Mouse, removable HDD and U flash disk backup and upgrade.
Network Interface One RJ-45 10M/100M self-adaptable Ethernet interface.
Network Function
Support Mobile surveillance, IE browser, Remote Live surveillance and
parameter setting.
Network Protocol Supports TCP/IP, DHCP, UDP, DDNS, PPPOE and UPNP network Protocol
IR remote control Support IR remote control.
Power Adapter DC 12V&5A
Power Consumption 10~15W (excluding HDD)
Operational Temperature
10℃~+40℃
Operational Humidity
10%~90%
List 7-1
