4 Commissioning
4.1 Notes for operation
ATTENTION!
• Notes on safety
During operation pay attention to the notes on safety in chapter1
• During operation
Strictly avoid that ...
− foreign objects or moisture enters into the device
− aggressive or conductive substances are in the vicinity
− ventilation openings are covered
• Cooling
− The device heats up during the operation and the temperature on the
heat may reach +100°C (+212°F). Danger of skin injury when touching.
− Cooling air must be able to flow through the device without restriction.
!
4.2 Initial commissioning
Once the MSDServoDriveCompact has been installed as described in chapter 2 and
wired with all required voltage supplies and external components as described in
chapter3, initial commissioning can performed in the following sequence:
Step Action Comment
1.
Installation and start of PC software
see Installation Manual
Moog
DriveADministr Ator5
2.
Switching on control voltage see section4.2.1
3.
Connection between PC and drive see section4.2.2
4.
Parameter setting see section4.2.3
5.
Drive control with Moog DriveADm inistrAtor 5 see section4.2.4
NOTE: Details concerning STO (Safe Torque Off) have not been taken into
account for initial commissioning, see chapter6
