A.3 Ambient conditions
Ambient conditions MSDServoDriveCompact
Protection IP20 except terminals (IP00)
Accident prevention
regulations
according to local regulations (in Germany e.g. BGVA3)
Mounting height
up to 1000 m above MSL, over 1000 m above MSL with power
reduction (1% per 100 m, maximum 2000 m above MSL)
Pollution severity 2
Type of installation
Built-in unit, only for vertical installation in a switch cabinet with
min. IP4x protection, when using STO safety function min. IP54
Table A.6 Ambient conditions MSDServoDriveCompact
Climatic conditions MSDServoDriveCompact
in transit
as per EN61800-2, IEC60721-3-2 class 2K3
1)
Temperature -25°C to +70°C (-13°F to +158°F)
Relative air humidity 95% at maximum +40°C (+104°F)
in storage
as per EN61800-2, IEC60721-3-1 class 1K3 and 1K4
2)
Temperature -25°C to +55°C (-13°F to +131°F)
Relative air humidity 5 to 95%
in operation
as per EN61800-2, IEC60721-3-3 class 3K3
3)
Temperature
-10°C to +45°C (+14°F to +113°F) (4kHz), up to +55°C
(+131°F) with power reduction (2%per °C/°F)
-10°C to +40°C (+14°F to +104°F) (8, 16kHz), up to
+55°C (+131°F) with power reduction (2%per °C/°F)
Relative air humidity 5 to 85% witout condensation
1) The absolute humidity is limited to maximum 60g/m³. This means, at +70°C (+158°F) for example, that the relative humidity
may only be maximum 40%.
2) The absolute humidity is limited to maximum 29g/m³ . So the maximum values for temperature and relative air humidity
stipulated in the table must not occur simultaneously.
3) The absolute humidity is limited to maximum 25g/m³. That means that the maximum values for temperature and relative air
humidity stipulated in the table must not occur simultaneously.
Table A.7 Climatic conditions MSDServoDriveCompact
Mechanical conditions MSDServoDriveCompact
Vibration limit in
transit
as per EN61800-2, IEC60721-3-2 class 2M1
Frequency [Hz] Amplitude [mm] Acceleration [m/s²]
2≤f<9 3.5 not applicable
9≤f<200 not applicable 10
200≤f<500 not applicable 15
Shock limit in transit
as per EN61800-2, IEC60721-2-2 class 2M1
Drop height of packed device maximum 0.25m
Vibration limit of the
system
1)
as per EN61800-2, IEC60721-3-3 class 3M1
Frequency [Hz] Amplitude [mm] Acceleration [m/s²]
2≤f<9 0.3 not applicable
9≤f<200 not applicable 1
1) NOTE: The devices are only designed for stationary use.
Table A.8 Mechanical conditions MSDServoDriveCompact
ATTENTION!
• No continuous vibrations!
The servo drives must not be installed in areas where they would be
permanently exposed to vibrations.
• Control cabinet min. IP54 for STO!
According to EN ISO 13849-2, when using the STO (Safe Torque OFF) safety
function the switch cabinet must have IP54 protection or higher.
• Observe cooling conditions!
Forced cooling by external air flow necessary. Air must be able to flow
unhindered through the device (air flow at least 1.2 m/s). If a temperature
cut-out occurs, the cooling conditions must be improved.
!
